| Camera | ||
|---|---|---|
| Image Sensor: | 2.0 megapixel progressive scan CMOS | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1920(H)*1080(V) | |
| Shutter Time: | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
|
| Lens Mount: | M12 | |
| Adjustment Range: | Pan: 0 to 360°, Tilt: 0 to 180°, Rotation 0 to 360° ° | |
| Day& Night: | ICR | |
| Video Frame Rate: | PAL: 1080p@25fps NTSC: 1080p@30fps |
|
| WDR (Wide Dynamic Range) | Digital WDR | |
| Min. illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR | |
| Menu | ||
|---|---|---|
| Image Mode | STD | |
| AE (Auto Exposure) Mode | DWDR/BLC/HLC/Global | |
| D/N Mode: | Auto/Color/BW (Black and White) | |
| AGC: | Yes | |
| White Balance | Auto | |
| Language: | English | |
| Function: | Brightness, Sharpness, DNR, Mirror, Smart IR | |
| Interface | ||
|---|---|---|
| Video Out: | Switchable TVI/AHD/CVI/CVBS | |
| General | ||
|---|---|---|
| Material: | Metal | |
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±25% | |
| Power Consumption: | Max. 3.7 W | |
| Weather Proof: | IP67 | |
| IR Range: | Up to 20m | |
| Dimension: | 58 mm × 61 mm × 163 mm (2.28″ × 2.40″ × 6.42″) | |
| Weight: | Approx. 335 g (0.74 lb.) | |
